Stainless Steel 304 S One - way Rexroth Hydraulic Valves
Product Details:
| Place of Origin: | China |
| Brand Name: | SJ HYD |
| Certification: | ISO9001 |
| Model Number: | S One - way |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pc |
|---|---|
| Packaging Details: | Carton or wooden box |
| Delivery Time: | One month |
| Payment Terms: | T/T or L/C |
| Supply Ability: | 1000 pcs per month |
|
Detail Information |
|||
| High Light: | hydraulic pressure relief valve,hydraulic safety valves,hydraulic relief valve |
||
|---|---|---|---|
Product Description
Stainless Steel 304 S One - way Rexroth Hydraulic Valves
Features:
Material:
1) the ATR-way valve standard configuration for the carbon steel body (one-way valve of stainless steel ATR quantities ordered);
2) RSVI one-way valve is stainless steel 304.
Seal: 1) the ATR-way valve spool with metal to metal hard seal between the valve seat;
2) RSVI one-way valve spool Viton soft seal
Operating temperature:
1) the ATR carbon steel check valve -30 ° C to +200 ° C;
2) the ATR hard sealed stainless steel check valve -60 ° C ~ +400 ° C (one-way valve of stainless steel ATR required quantities ordered);
3) RSVI soft stainless steel sealing one-way valve from -25 ° C ~ +200 ° C
Working pressure:
1) the ATR carbon steel one-way valve 350bar;
2) RSVI stainless steel soft-sealing check valve 250 ~ 400bar
Interface Type: British straight pipe. BSPP thread (G thread).
Spool structure: the movement of the spool axial-oriented features, and help extend the spool applies to life.
The check valve spring opening pressure: 1) the ATR check valve standard on pressure for 0.35bar (5 psi)
