Crawler Mini Excavator Machine 900kg Small Digger Machine Bucket Capacity 0.025cbm

Crawler Mini Excavator Machine 900kg Small Digger Machine Bucket Capacity 0.025cbm

Product Details:

Place of Origin: CHINA
Brand Name: SJ HYDRAULIC
Certification: ISO9001
Model Number: SJ08

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: USD 1
Packaging Details: Standard package
Delivery Time: 15 days after received the payment
Payment Terms: L/C, T/T
Supply Ability: 500 set per month
Get Best Price Contact Now

Detail Information

Chassis Width: 896mm Bucket Capacity: 0.025cbm
Machine Weight: 900kgs Dimensions: 2770*896*1490mm
Track Width: 130mm Maximum Digging Height: 2610mm
Buchet Width: 350mm Rated Speed: 1.5km/h
Condition: New Material: Casting And Iron
High Light:

mini excavation equipment

,

small digger machine

Product Description

crawler mini excavators 900kg small digging machine

1.Main Features

1) Simple structure and compact design ,easy in installation and maintation.

2) Advanced world famous brand components

3) Low oil consumption, to obtain maximum efficiency

4) Wide range use: Auger, grab, hydraulic hammer, narrow bucket



2.Application
1) 0.8 ton mini MR08 excavator with compact design, it is suitable to be used for small works, small projects, in garden, farmland, municipal works,vegetable greenhouse, digging trench



3.Advantages:



1. The hydraulic system and Multi-valve of our machine adopt loop pressure compensation,

load sensitive type valve, and non-pressure interference, so make the operation coordination.



2. Select the latest diesel engine, emissions meet the National standardⅡ.
Structural parts holes are made by full automatic numerical control fine boring, gap precision,

well lubrication; surface with shot blasting, paint surface has strong adhesive force;

cab and covering parts are processing with electrophoresis.
Super wide X type frame, more strength and stability.


3. Beautiful cab specially designed according to human engineering,

and equipped with all-weather air conditioner, and a built-in cushion pad to reduce vibration.

Making the driving environment safer and more reliable. It is featured by compact design,

flexible movement and convenient operation.



4.Main Specification



Operating Weight

900kg

Digging bucket capacity

0.025cbm/100kg

Bucket width

340mm

Engine

KOOP

Rated power

8.6 kw/3600r/min

Displacement

0.211 L

Bore stroke

70x55

Main pump

CBK-F6.8

Displacement

6.8ml/r

Swing motor

SJ HYD

Traveling motor

SJ HYD

Travel speed

1.5km/h

MAIN DEMENSIONS

Overall dimension( LxWxH)

2770x896x1490 mm

Wheelbase

910 mm

Total length of track

1230mm

Platform ground clearance

380 mm

Platform back turning radius

784 mm

Chassis width

896 mm

Track width

150 mm

Chassis ground clearance

132 mm

Track height

320 mm

OPERATING RANGE

Max. Digging depth

1650 mm

Max. Vertical digging depth

1375 mm

Max. Digging height

2610 mm

Max. Dumping height

1850 mm

Max. Digging radius on ground

2850 mm

Min. Rotation radius

1330 mm

Max. Upgrade height of bulldozer blade

345 mm

Max. Digging depth of bulldozer blade

255 mm



Crawler Mini Excavator Machine 900kg Small Digger Machine Bucket Capacity 0.025cbm 0Crawler Mini Excavator Machine 900kg Small Digger Machine Bucket Capacity 0.025cbm 1



5.Packing&Delivery







Crawler Mini Excavator Machine 900kg Small Digger Machine Bucket Capacity 0.025cbm 2

>Production Time: Within 7 days after order confirmed

>If 1 unit , in wooden case;

One 20'GP Container , load 12 units ;

One 40'HQ Container , Load 24 units.
